Multi-level track structures

Improve the userreturn rate by 45%

You can create the ultimate karting entertainment destination with 360K organically shaped multi-level track structures that resemble natural movements and provide the best driving experience.

At the same time, the safety of drivers is not compromised – 360K multi-level track technology increases safety to the highest level.

The Highest Return Rate on the Market

Best Driving Experience

Roller Coaster Experience: 360K track design with organic flow enables the highest number of elevation changes per surface area, for the best karting experience in the world!

Unprecedented Safety

Lowering Impact Angles: Organically shaped elevated track design increases drivers’ safety to the highest level.
The track’s smooth layout always follows the ideal driving lines, and therefore completely prevents 90° impacts and significantly decreases others. Consequently, there are also lower maintenance costs for go-karts.

WOW Effect

Highest use of Space: 360K organically shaped technology brings the highest use of your entertainment center volume and brings to you the advantages of renting premium spaces for an anchor attraction that traditionally creates lots of attention on the market.

Enjoying Gravity

Smooth Transitions: 360K transition elements have been designed with mathematical curves to allow the fastest yet smoothest elevation transition on the market. Why is this so important? Because the go-karts do not suffer stress and the driving experience is not compromised due to unpleasant grinding or loss of control, while at the same time delivering fast transition at full speed that brings the gravitational experience of flying or being squeezed to the ground.

Multi-Level Track Technology

01
02
03
04
05
06
07
08
09
10
11
12
01

Side Rails

The key structural element with a 3D spiral shape is the only one on the market. It enables 360K to create a unique and fluid spiral elevation change experience for drivers.

Benefit: Roller coaster effect.

02

Central Rail

Secondary structural element following the side rails’ organically shaped multi-level layout.

Benefit: Roller coaster effect.

03

Supporting Structure

A completely independent sub-system, custom-designed to leave the absolute
freedom to the shaping of the ground floor track trajectory.

Benefit: Complete freedom of ground floor track trajectory.

04

Anchoring & Flanges

Code compliant and separately calculated system, suitable also for thinner or low-quality concrete slabs.

Benefit: Complete freedom of ground floor track trajectory.

05

Joints

Certified and precalculated screw joints as part of structural static documentation,
in conformity with ISO standards and IBC code.

Benefit: Complete freedom of ground floor track trajectory.

06

Safety Barrier System

Developed to follow the 3D trajectories. Due to its integration into the structural side rail, it brings the same 360K ETAT performance as all other 360K safety barrier systems.

Benefit: Uncompromised safety on the 3D trajectory.

07

Safety Railings

Compliant with IBC, FFSA, ADAC …

Benefit: Uncompromised safety on the 3D trajectory.

08

Driving Surface

Ultralight structural floor system with optic lines and superior grip for go-karting.

Benefit: Lighter structure with superior grip.

09

LED Theming

Designed and manufactured programmable LED illumination, specialized for the karting entertainment business.

Benefit: Improved visibility and safety.

10

Under Ramp Covers

Customized under ramp covers made of perforated sheet metal for a clean and compact view of the track.

Benefit: Additional storage space.

11

Track Marshal Post

Elevated podium for track marshals, which improves their safety and gives them a better overlook of the track.

Benefit: Improved safety for track marshals.

12

Stairs

For track marshal’s access on multi-level track to ease the overview and improve the ability to control the track. Also used for visitors’ access to elevated on-track platforms.

Benefit: Easy access to elevated areas of the track.

Multi-Level Experience Elements

Flyover

Driving experience: A dynamic and eye-catching multi-level feature that gives drivers a feeling of flying.



Structure length: 102 lin. ft (31 m)
Elevation change: +/- 8.5 lin. ft (2.6 m)
Min. space required: 2024 sq. ft (188 m2)
Min. height required: 16.4 lin. ft (5 m)

Dive-under

Driving experience: With dive-under structure, the drivers will smoothly descend from the multi-level section to the ground floor and back up.



Structure length: 102 lin. ft (31 m)
Elevation change: +/- 8.5 lin. ft (2.6 m)
Min. space required: 2024 sq. ft (188 m2)
Min. height required: 16.4 lin. ft (5 m)

Double S 90

Driving experience: Advanced driving experience with double technical left and right turns.



Double S 90
Structure length: 118 lin. ft (36 m)
Elevation change: +/- 5 lin. ft (1.5 m)
Min. space required: 2314 sq. ft (215 m2)
Min. height required: 13 lin. ft (4 m)

Double S 180

Driving experience: Advanced driving experience with double technical left and right turns.



Double S 180
Structure length: 190 lin. ft (58 m)
Elevation change: +/- 8.5 lin. ft (2.6 m)
Min. space required: 3660 sq. ft (340 m2)
Min. height required: 16.4 lin. ft (5 m)

Double S 270

Driving experience: Advanced driving experience with double technical left and right turns.



Double S 270
Structure length: 276 lin. ft (84 m)
Elevation change: +/- 12 lin. ft (3.7 m)
Min. space required: 6286 sq. ft (584 m2)
Min. height required: 20 lin. ft (6 m)

Double S 360

Driving experience: Advanced driving experience with double technical left and right turns.



Double S 360
Structure length: 405 lin. ft (124 m)
Elevation change: +/- 17 lin. ft (5.2 m)
Min. space required: 6458 sq. ft (600 m2)
Min. height required: 25 lin. ft (7.5 m)

SSE 90

Driving experience: A compelling structure that enhances the driving experience, saves space, and makes the track layout even more entertaining. 360K is the only provider of straight & spiral elevation structure for go-kart track on the market.



Straight & Spiral Elevation 90
Structure length: 102 lin. ft (31 m)
Elevation change: +/- 5 lin. ft (1.5 m)
Min. space required: 1884 sq. ft (175 m2)
Min. height required: 13 lin. ft (4 m)

SSE 180/1

Driving experience: A compelling structure that enhances the driving experience, saves space, and makes the track layout even more entertaining. 360K is the only provider of straight & spiral elevation structure for go-kart track on the market.



Straight & Spiral Elevation 180/1
Structure length: 151 lin. ft (46 m)
Elevation change: +/- 8.5 lin. ft (2,6 m)
Min. space required: 2885 sq. ft (268 m2)
Min. height required: 16.4 lin. ft (5 m)

SSE 180/2

Driving experience: A compelling structure that enhances the driving experience, saves space, and makes the track layout even more entertaining. 360K is the only provider of straight & spiral elevation structure for go-kart track on the market.



Straight & Spiral Elevation 180/2
Structure length: 254 lin. ft (77.5 m)
Elevation change: +/- 14 lin. ft (4.3 m)
Min. space required: 6135 sq. ft (570 m2)
Min. height required: 21 lin. ft (6.5 m)

SSE 180/3

Driving experience: A compelling structure that enhances the driving experience, saves space, and makes the track layout even more entertaining. 360K is the only provider of straight & spiral elevation structure for go-kart track on the market.



Straight & Spiral Elevation 180/3
Structure length: 303.5 lin. ft (92.5 m)
Elevation change: +/- 17 lin. ft (5.2 m)
Min. space required: 6458 sq. ft (600 m2)
Min. height required: 25 lin. ft (7.5 m)

Banked Semi-Oval SMALL

Driving experience: Banked semi-oval structure enhances the racing experience on the track with the feeling of centrifugal force while driving.



Small
Structure length: 72 lin. ft (22 m)
Elevation change: +/- 3.3 lin. ft (1 m)
Min. space required: 1981 sq. ft (184 m2)
Min. height required: 11.5 lin. ft (3.5 m)

Banked Semi-Oval MEDIUM

Driving experience: Banked semi-oval structure enhances the racing experience on the track with the feeling of centrifugal force while driving.



Medium
Structure length: 92 lin. ft (28 m)
Elevation change: +/- 5 lin. ft (1.5 m)
Min. space required: 2583 sq. ft (240 m2)
Min. height required: 13 lin. ft (4 m)

Banked Semi-Oval LARGE

Driving experience: Banked semi-oval structure enhances the racing experience on the track with the feeling of centrifugal force while driving.



Large
Structure length: 151 lin. ft (46 m)
Elevation change: +/- 8 lin. ft (2.5 m)
Min. space required: 4574 sq. ft (425 m2)
Min. height required: 16.4 lin. ft (5 m)

  • Flyover Driving experience: A dynamic and eye-catching multi-level feature that gives drivers a feeling of flying. Structure length: 102 lin. ft (31 m) Elevation change: +/- 8.5 lin. ft (2.6 m) Min. space required: 2024 sq. ft (188 m2) Min. height required: 16.4 lin. ft (5 m)

    Flyover

    Driving experience: A dynamic and eye-catching multi-level feature that gives drivers a feeling of flying.

    Structure length: 102 lin. ft (31 m)
    Elevation change: +/- 8.5 lin. ft (2.6 m)
    Min. space required: 2024 sq. ft (188 m2)
    Min. height required: 16.4 lin. ft (5 m)

  • Dive-under Driving experience: With dive-under structure, the drivers will smoothly descend from the multi-level section to the ground floor and back up. Structure length: 102 lin. ft (31 m) Elevation change: +/- 8.5 lin. ft (2.6 m) Min. space required: 2024 sq. ft (188 m2) Min. height required: 16.4 lin. ft (5 m)

    Dive-under

    Driving experience: With dive-under structure, the drivers will smoothly descend from the multi-level section to the ground floor and back up.

    Structure length: 102 lin. ft (31 m)
    Elevation change: +/- 8.5 lin. ft (2.6 m)
    Min. space required: 2024 sq. ft (188 m2)
    Min. height required: 16.4 lin. ft (5 m)

  • Double S 90 Driving experience: Advanced driving experience with double technical left and right turns. Double S 90 Structure length: 118 lin. ft (36 m) Elevation change: +/- 5 lin. ft (1.5 m) Min. space required: 2314 sq. ft (215 m2) Min. height required: 13 lin. ft (4 m)

    Double S 90

    Driving experience: Advanced driving experience with double technical left and right turns.

    Double S 90
    Structure length: 118 lin. ft (36 m)
    Elevation change: +/- 5 lin. ft (1.5 m)
    Min. space required: 2314 sq. ft (215 m2)
    Min. height required: 13 lin. ft (4 m)

  • Double S 180 Driving experience: Advanced driving experience with double technical left and right turns. Double S 180 Structure length: 190 lin. ft (58 m) Elevation change: +/- 8.5 lin. ft (2.6 m) Min. space required: 3660 sq. ft (340 m2) Min. height required: 16.4 lin. ft (5 m)

    Double S 180

    Driving experience: Advanced driving experience with double technical left and right turns.

    Double S 180
    Structure length: 190 lin. ft (58 m)
    Elevation change: +/- 8.5 lin. ft (2.6 m)
    Min. space required: 3660 sq. ft (340 m2)
    Min. height required: 16.4 lin. ft (5 m)

  • Double S 270 Driving experience: Advanced driving experience with double technical left and right turns. Double S 270 Structure length: 276 lin. ft (84 m) Elevation change: +/- 12 lin. ft (3.7 m) Min. space required: 6286 sq. ft (584 m2) Min. height required: 20 lin. ft (6 m)

    Double S 270

    Driving experience: Advanced driving experience with double technical left and right turns.

    Double S 270
    Structure length: 276 lin. ft (84 m)
    Elevation change: +/- 12 lin. ft (3.7 m)
    Min. space required: 6286 sq. ft (584 m2)
    Min. height required: 20 lin. ft (6 m)

  • Double S 360 Driving experience: Advanced driving experience with double technical left and right turns. Double S 360 Structure length: 405 lin. ft (124 m) Elevation change: +/- 17 lin. ft (5.2 m) Min. space required: 6458 sq. ft (600 m2) Min. height required: 25 lin. ft (7.5 m)

    Double S 360

    Driving experience: Advanced driving experience with double technical left and right turns.

    Double S 360
    Structure length: 405 lin. ft (124 m)
    Elevation change: +/- 17 lin. ft (5.2 m)
    Min. space required: 6458 sq. ft (600 m2)
    Min. height required: 25 lin. ft (7.5 m)

  • SSE 90 Driving experience: A compelling structure that enhances the driving experience, saves space, and makes the track layout even more entertaining. 360K is the only provider of straight & spiral elevation structure for go-kart track on the market. Straight & Spiral Elevation 90 Structure length: 102 lin. ft (31 m) Elevation change: +/- 5 lin. ft (1.5 m) Min. space required: 1884 sq. ft (175 m2) Min. height required: 13 lin. ft (4 m)

    SSE 90

    Driving experience: A compelling structure that enhances the driving experience, saves space, and makes the track layout even more entertaining. 360K is the only provider of straight & spiral elevation structure for go-kart track on the market.

    Straight & Spiral Elevation 90
    Structure length: 102 lin. ft (31 m)
    Elevation change: +/- 5 lin. ft (1.5 m)
    Min. space required: 1884 sq. ft (175 m2)
    Min. height required: 13 lin. ft (4 m)

  • SSE 180/1 Driving experience: A compelling structure that enhances the driving experience, saves space, and makes the track layout even more entertaining. 360K is the only provider of straight & spiral elevation structure for go-kart track on the market. Straight & Spiral Elevation 180/1 Structure length: 151 lin. ft (46 m) Elevation change: +/- 8.5 lin. ft (2,6 m) Min. space required: 2885 sq. ft (268 m2) Min. height required: 16.4 lin. ft (5 m)

    SSE 180/1

    Driving experience: A compelling structure that enhances the driving experience, saves space, and makes the track layout even more entertaining. 360K is the only provider of straight & spiral elevation structure for go-kart track on the market.

    Straight & Spiral Elevation 180/1
    Structure length: 151 lin. ft (46 m)
    Elevation change: +/- 8.5 lin. ft (2,6 m)
    Min. space required: 2885 sq. ft (268 m2)
    Min. height required: 16.4 lin. ft (5 m)

  • SSE 180/2 Driving experience: A compelling structure that enhances the driving experience, saves space, and makes the track layout even more entertaining. 360K is the only provider of straight & spiral elevation structure for go-kart track on the market. Straight & Spiral Elevation 180/2 Structure length: 254 lin. ft (77.5 m) Elevation change: +/- 14 lin. ft (4.3 m) Min. space required: 6135 sq. ft (570 m2) Min. height required: 21 lin. ft (6.5 m)

    SSE 180/2

    Driving experience: A compelling structure that enhances the driving experience, saves space, and makes the track layout even more entertaining. 360K is the only provider of straight & spiral elevation structure for go-kart track on the market.

    Straight & Spiral Elevation 180/2
    Structure length: 254 lin. ft (77.5 m)
    Elevation change: +/- 14 lin. ft (4.3 m)
    Min. space required: 6135 sq. ft (570 m2)
    Min. height required: 21 lin. ft (6.5 m)

  • SSE 180/3 Driving experience: A compelling structure that enhances the driving experience, saves space, and makes the track layout even more entertaining. 360K is the only provider of straight & spiral elevation structure for go-kart track on the market. Straight & Spiral Elevation 180/3 Structure length: 303.5 lin. ft (92.5 m) Elevation change: +/- 17 lin. ft (5.2 m) Min. space required: 6458 sq. ft (600 m2) Min. height required: 25 lin. ft (7.5 m)

    SSE 180/3

    Driving experience: A compelling structure that enhances the driving experience, saves space, and makes the track layout even more entertaining. 360K is the only provider of straight & spiral elevation structure for go-kart track on the market.

    Straight & Spiral Elevation 180/3
    Structure length: 303.5 lin. ft (92.5 m)
    Elevation change: +/- 17 lin. ft (5.2 m)
    Min. space required: 6458 sq. ft (600 m2)
    Min. height required: 25 lin. ft (7.5 m)

  • Banked Semi-Oval SMALL Driving experience: Banked semi-oval structure enhances the racing experience on the track with the feeling of centrifugal force while driving. Small Structure length: 72 lin. ft (22 m) Elevation change: +/- 3.3 lin. ft (1 m) Min. space required: 1981 sq. ft (184 m2) Min. height required: 11.5 lin. ft (3.5 m)

    Banked Semi-Oval SMALL

    Driving experience: Banked semi-oval structure enhances the racing experience on the track with the feeling of centrifugal force while driving.

    Small
    Structure length: 72 lin. ft (22 m)
    Elevation change: +/- 3.3 lin. ft (1 m)
    Min. space required: 1981 sq. ft (184 m2)
    Min. height required: 11.5 lin. ft (3.5 m)

  • Banked Semi-Oval MEDIUM Driving experience: Banked semi-oval structure enhances the racing experience on the track with the feeling of centrifugal force while driving. Medium Structure length: 92 lin. ft (28 m) Elevation change: +/- 5 lin. ft (1.5 m) Min. space required: 2583 sq. ft (240 m2) Min. height required: 13 lin. ft (4 m)

    Banked Semi-Oval MEDIUM

    Driving experience: Banked semi-oval structure enhances the racing experience on the track with the feeling of centrifugal force while driving.

    Medium
    Structure length: 92 lin. ft (28 m)
    Elevation change: +/- 5 lin. ft (1.5 m)
    Min. space required: 2583 sq. ft (240 m2)
    Min. height required: 13 lin. ft (4 m)

  • Banked Semi-Oval LARGE Driving experience: Banked semi-oval structure enhances the racing experience on the track with the feeling of centrifugal force while driving. Large Structure length: 151 lin. ft (46 m) Elevation change: +/- 8 lin. ft (2.5 m) Min. space required: 4574 sq. ft (425 m2) Min. height required: 16.4 lin. ft (5 m)

    Banked Semi-Oval LARGE

    Driving experience: Banked semi-oval structure enhances the racing experience on the track with the feeling of centrifugal force while driving.

    Large
    Structure length: 151 lin. ft (46 m)
    Elevation change: +/- 8 lin. ft (2.5 m)
    Min. space required: 4574 sq. ft (425 m2)
    Min. height required: 16.4 lin. ft (5 m)

New spiral ramp

Invest in the most advanced karting solutions
